In mechanical design and materials science, fundamental concepts such as Rigidity, strength, and hardness are essential knowledge that engineers and technicians must master accurately. Although these terms may seem similar, they each have distinct physical definitions and engineering significance. This article will systematically analyze the essential differences among these eight key performance parameters.



I. Rigidity - The ability to resist elastic deformation

Rigidity is the ability of a material or structure to resist deformation within the elastic range, and its quantitative indicator is the elastic modulus (E). According to Hooke's Law, in the elastic deformation stage, stress is directly proportional to strain: σ = E·ε.



Engineering application examples:

Machine tool spindles: High Rigidity ensures machining accuracy

Precision measurement platforms: Minor deformation affects measurement results

Bridge design: Insufficient Rigidity leads to excessive deflection



II. Strength - The ability to resist damage

Strength refers to a material's capacity to resist permanent deformation and fracture, and it is characterized by several key indicators:



Yield strength (σs): The stress value at which significant plastic deformation begins

Tensile strength (σb): The maximum stress a material can withstand before fracture

Fatigue strength: The endurance limit under alternating loads

Data comparison:

Q235 steel: Yield strength 235 MPa

6061 aluminum alloy: Yield strength 275 MPa

Ti-6Al-4V titanium alloy: Tensile strength 895 MPa





III. Hardness - The ability to resist local indentation

Hardness characterizes a material's surface resistance to local plastic deformation. Common testing methods include:



Brinell Hardness (HB): suitable for softer materials

Rockwell Hardness (HR): divided into scales such as A, B, and C

Vickers Hardness (HV): highest precision and wide application range

Relationship between hardness and strength: For steel, tensile strength σb ≈ 3.5×HB (empirical formula)



IV. Elasticity and Plasticity - The Recoverability of Deformation

Elasticity: The property where deformation completely disappears after the removal of external force.



Ideal elastic body: Deformation immediately recovers without energy loss.

Actual materials: Hysteresis phenomenon exists.

Plasticity: The ability of a material to undergo permanent deformation

Plasticity indicators: Elongation after fracture (δ) and reduction of area (ψ)

Engineering significance: Evaluation of formability and processability





V. Toughness - The ability to absorb energy without breaking

Toughness is the ability of a material to absorb energy throughout the process from deformation to fracture, and it is a comprehensive manifestation of strength and plasticity:



Impact toughness (AKU): The energy value measured by the Charpy impact test

Fracture toughness (KIC): The ability to resist crack propagation

Typical data:

Ordinary glass: Nearly zero toughness

Low-carbon steel: High-toughness material

Polymer materials: Large range of toughness variation





VI. Rigidity and Deflection - Structural Performance Parameters

Rigidity generally refers to the overall ability of a structure to resist deformation, which is the manifestation of Rigidity at the structural level.

Deflection is the displacement of beams, slabs, and other components under load. The calculation formula is:

δ = (F·L³)/(3·E·I)





where E is the modulus of elasticity and I is the moment of inertia of the cross-section.

Comparison Table of Seven and





VII. Eight Major Performance Parameters for Engineering Projects

Performance parameters	Physical meaning	Measurement unit	Influencing factors
Rigidity	Resistance to elastic deformation	GPa	Material nature, temperatureconditions
Intensity	Resistance to damage	MPa	Composition, heat treatment
Hardness	Resistance to local indentation	HB/HR/HV	Crystal structure, defects
Elasticity	Deformation recovery ability	Elastic limit	Interatomic bonding force
Plasticity	Permanent deformation ability	δ, Ψ	Grain size, temperature
Toughness	Absorption of impact energy	J/cm2	Microstructure uniformity
Deflection	Deformation displacement amount	mm	Load with constraint







IX. Collaboration and Trade-offs in Engineering Design

In practical engineering design, parameter trade-offs need to be made based on specific working conditions:



Contradictory relationships:

High strength vs. high toughness: Usually difficult to achieve both

High hardness vs. good plasticity: One increases at the expense of the other

High Rigidity vs. lightweight: Optimization design is required

Collaborative design strategies:

Surface hardening treatment: Maintain toughness in the core while achieving high hardness on the surface

Composite material application: Multi-layer structure for complementary performance

Structural optimization design: Enhance overall rigidity through geometric shape



X. Rigorous Engineering Selection Criteria

When choosing material performance indicators, the following criteria must be followed:

Primary failure mode analysis: Determine the main cause of part failure

Safety factor determination: Select an appropriate coefficient based on reliability requirements

Economic assessment: Optimize costs while meeting performance requirements

Process feasibility: Consider the impact of manufacturing processes on performance



XI. Conclusion

Mastering the essential differences among these eight mechanical performance parameters is the foundation for reasonable mechanical design. In practical engineering, materials should be scientifically selected and structural forms determined based on the service conditions, failure modes and economic requirements of parts, to achieve the unification of safety, reliability and economy. A correct understanding of these concepts will directly affect the quality of engineering design and the service life of products.
