In the world of metal surface treatment, passivation, phosphatization, chromium plating, and anodizing are like four "surface engineers" with distinct personalities, each communicating with metals in their unique chemical language. They either activate the inherent corrosion resistance potential of metals through oxidation reactions or endow metals with new physical properties through deposition and transformation. This article will explore the essential differences among these four surface treatment processes from three dimensions: reaction mechanism, film layer nature, and application logic, revealing their unique positions in materials science.

The core of passivation is "self-oxidation" - taking stainless steel as an example, the chromium element on its surface spontaneously forms a dense chromium trioxide (Cr₂O₃) passivation film in weakly oxidizing media such as nitric acid and citric acid. This reaction does not require an external power source and relies solely on the electrochemical activity of the metal itself, which is a "self-passivation" process. The film thickness is only 1-5 nanometers, yet it can reduce the corrosion current density to less than 1/10 of the untreated surface, making it a "self-repair" mechanism for metals.



Phosphating is a "chemical conversion" feast. On the surface of steel, complex reactions occur in a phosphoric acid-zinc/manganese salt solution, generating phosphate crystals (such as Zn₃(PO₄)₂·4H₂O) and forming a porous and slightly rough conversion film. This film layer is typically 2-15 micrometers thick. Its value does not lie in corrosion resistance itself, but in providing "anchor points" for subsequent painting and electrophoresis - the porous structure mechanically bonds with the coating, increasing adhesion by 3-5 times.



Chromium plating is a typical "electrodeposition" process. In a chromic acid electrolyte, a chromium layer up to 10-50 micrometers thick is deposited on the metal surface through a cathodic reduction reaction. This layer of chromium not only has a hardness of 800-1000HV (approaching that of diamond), but also has a mirror-like reflectivity and excellent corrosion resistance. However, the cost of chromium plating is its environmental impact - hexavalent chromium wastewater requires complex treatment and has high energy consumption.



Anodizing is the "electrochemical rebirth" of aluminum and aluminum alloys. In sulfuric acid or oxalic acid electrolytes, aluminum acts as the anode and loses electrons, forming an aluminum oxide (Al₂O₃) film 10-150 micrometers thick on the surface. This film layer has a unique "double-layer structure": the outer layer is porous and can be dyed, while the inner layer is dense and blocks corrosion. Even more fascinating is that by adjusting the electrolytic parameters, the pore size of the film layer can be controlled, achieving different textures from matte to mirror-like.



The essence of passivation films is "chemical conversion films", and their most significant feature is "not changing the base material composition, but only optimizing the surface state". Taking the passivation of stainless steel as an example, the chromium element in the film layer still exists in the +3 oxidation state and forms a continuous transition with the base material, without interface defects. This "interface-free" characteristic gives the film layer excellent adhesion and prevents cracking due to differences in thermal expansion coefficients.

The phosphating film is a composite of "chemical conversion and mechanical anchoring". Phosphate crystals grow in a dendritic pattern on the steel surface, creating a microscopic roughness. This structure not only enhances the adhesion of the coating but also delays crack propagation by absorbing stress. However, the corrosion resistance of the phosphating film is limited and it needs to be used in conjunction with painting or anti-rust oil, belonging to a "function superimposition type" treatment.

The chromium plating layer is a "metal deposition film" with a distinct "interface". The chromium layer is connected to the substrate through metallurgical or mechanical bonding, and there is a difference in thermal expansion coefficients. This difference may cause the film to peel off under high temperatures or alternating stresses, but the hardness and wear resistance of chromium plating make it the preferred choice for molds, piston rings, and other components.

The anodic oxidation film is an "electrochemical conversion film" with "dual-function" characteristics. The dense layer blocks corrosive media, and the porous layer can adsorb dyes or lubricants. More importantly, the anodic oxidation film can further enhance corrosion resistance through a "sealing" process, forming a functional closed loop from "protection" to "decoration".

The application logic of passivation is "corrosion resistance first, color unchanged". In medical devices, food equipment, and marine engineering, passivated stainless steel can achieve excellent corrosion resistance without changing its appearance and does not affect subsequent welding, forming, and other processing. Its "invisible protection" feature makes it a standard configuration in high cleanliness scenarios.

The logic of phosphating is "basic protection, pre-treatment for painting". In automotive bodies and home appliance shells, the phosphating film serves as the "base layer" for electrophoretic painting, improving the adhesion of the coating and delaying substrate corrosion through the corrosion inhibition effect of phosphates. This "bridging" role makes it a core process in the painting production line.

The logic of chromium plating is "performance customization, appearance upgrade". In bathroom faucets and motorcycle parts, chromium plating not only provides a mirror-like appearance but also extends the service life through the wear resistance of the hard chromium layer. Its "decoration + function" dual attributes make it occupy a unique position in consumer goods and industrial components.

The logic of anodic oxidation is "material strengthening, function expansion". In architectural aluminum profiles and aerospace components, anodic oxidation not only improves corrosion resistance but also can achieve a colorful appearance through dyeing or enhance wear resistance through hard anodizing (such as military standards). This "one film, multiple functions" characteristic makes it a "universal key" for surface treatment of aluminum and aluminum alloys.

Passivation, phosphating, chromium plating, and anodizing are essentially different ways of communication between metals and chemical media. Passivation is the "self-awakening" of metals, activating their corrosion resistance potential through internal oxidation; phosphating is the "chemical transformation" of metals, generating functional film layers through conversion; chromium plating is the "external coating" of metals, endowing them with new properties through deposition; anodizing is the "electrochemical rebirth" of metals, achieving performance upgrades through electrolysis.



Understanding these essential differences lies not only in distinguishing process parameters but also in grasping the underlying logic of materials science - surface treatment is not merely a "coating overlay", but rather a reconfiguration of the electronic and crystal structures of the metal surface through chemical and electrochemical means, ultimately achieving a synergistic optimization of corrosion resistance, wear resistance, and decorative properties. This is precisely the profound philosophy of surface engineering as the "second skin" of materials.
