Knowledge

Alloying elements in steel



I. Strengthening Matrix Elements



1. Manganese (Mn)

The strengthening effect of manganese on steel is concentration-dependent:

Low content range (conventional addition): Through atomic solid solution strengthening mechanism, it embeds into the ferrite lattice causing distortion, significantly enhancing the strength and hardness of steel, and improving wear resistance, making steel more durable under mechanical stress and friction conditions (such as gears and shaft parts); it reduces the critical cooling rate, broadening the hardenability range of steel, allowing more cross-sectional areas to obtain martensitic structure during quenching, and optimizing the uniformity of mechanical properties; a small amount of manganese can also slightly adjust the low-temperature toughness of steel, alleviating the low-temperature embrittlement tendency of pure ferritic steel, meeting the service requirements in cold environments.

High content range (special alloying): As a strong austenitizing element, it can stabilize the austenite structure in steel, providing a basis for developing high-manganese austenitic steels (such as wear-resistant non-magnetic steel). These steels, due to their austenitic structure which combines high toughness with special physical properties (non-magnetism), have unique applications in construction machinery and magnetic shielding fields.



2. Silicon (Si)

Silicon is a strengthening element for ferrite:

It dissolves in ferrite in a solid solution form, significantly enhancing strength and hardness. In low-alloy structural steels, when combined with manganese, it can form a "silicon-manganese strengthening system", balancing strength and cost. It reduces the critical cooling rate and helps adjust the steel's hardenability. It plays a crucial role in spring steel and silicon steel - spring steel uses silicon to increase the elastic limit, while silicon steel relies on silicon to achieve specific magnetic permeability (silicon increases the resistance of ferrite and suppresses eddy current losses), making it a core material for power transformer cores. In oxidative environments (such as high-temperature air and weak corrosive media), silicon promotes the formation of a dense SiO2 protective film on the steel surface, preventing further oxygen penetration, and improving heat resistance and corrosion resistance. It is a fundamental alloying element in heat-resistant and weather-resistant steels.



3. Chromium (Cr)

The strengthening and modification effects of chromium span the entire range from low to high alloy:

In low alloy scenarios (such as alloy structural steel): Through solid solution strengthening and dispersion strengthening by carbides (such as Cr3C2), chromium simultaneously enhances the steel's strength, hardness, and wear resistance. For instance, in automotive gear steel, chromium is crucial for ensuring the wear resistance of the tooth surface and the toughness of the core. It reduces the critical cooling rate, enhancing the hardenability, allowing the core of large-sized parts to be hardened during quenching. A small amount of chromium can also improve the steel's oxidation resistance, delaying oxidation failure at high temperatures.

In high alloy scenarios (such as stainless steel and heat-resistant steel): When the chromium content is ≥12%, it imparts excellent corrosion resistance to the steel through the "passivation effect" (forming a dense Cr2O3 film on the surface), especially against strong oxidizing acids (such as nitric acid and concentrated sulfuric acid). Chromium has a variety of carbides (such as Cr7C3 and Cr23C6), and by controlling the morphology and distribution of carbides, it can regulate the high-temperature strength and thermal stability of the steel, making it a core component of heat-resistant steels (such as boiler tube steel).



II. Heat Resistance Optimization Elements



1. Molybdenum (Mo)

Molybdenum is a hallmark element in heat-resistant steels.

It solid-solution strengthens ferrite, enhancing both room temperature and high-temperature strength; it has a unique "delayed temper embrittlement" inhibitory effect, allowing molybdenum-containing steels to maintain toughness after long-term high-temperature service; it reduces the critical cooling rate, optimizing hardenability, and enables the steel to obtain a more uniform tempered sorbite structure after quenching + tempering; at high temperatures, molybdenum can form stable carbides (Mo2C), which prevent grain growth, strengthen grain boundaries, significantly enhance the steel's heat resistance and high-temperature strength, and is indispensable in turbine blade steels and hot working die steels.



2. Vanadium (V)

The role of vanadium is dual:

Low content (0.05% - 0.10%): It precipitates as fine carbonitrides (V(CN)), exerting a "fine grain strengthening" effect - hindering austenite grain growth, refining ferrite/pearlite structure, and significantly improving the steel's toughness and fatigue strength. It is a commonly used element in bridge steels and pipeline steels to achieve a "high strength + high toughness" match.

High content (>0.20%): It forms coarse V4C3 carbides, which are highly stable at high temperatures, can pin grain boundaries, and hinder dislocation movement, significantly enhancing the steel's heat resistance. In boiler heat-resistant steels and aero-engine blade alloys, vanadium carbides are the core barrier against high-temperature creep.



III. Elements for Organizational Regulation and Special Properties



1. Nickel (Ni)

While solid solution strengthening ferrite/austenite, the unique "face-centered cubic lattice" property effectively inhibits the cold brittleness of steel (lowering the cold brittleness transformation temperature), enabling nickel-containing steel to maintain toughness in extremely cold environments (such as liquid nitrogen storage tanks, polar engineering machinery). It reduces the critical cooling rate, enhances hardenability, and assists in obtaining a more uniform quenched structure. It expands the austenite zone and is a key component in austenitic stainless steels (such as 304 steel, where Ni stabilizes austenite) and low-temperature steels (such as 9Ni steel). Nickel itself has certain corrosion resistance, especially against reducing acids (sulfuric acid, hydrochloric acid), and can work in synergy with chromium to form a "chromium-nickel corrosion-resistant system", enhancing the overall corrosion resistance of stainless steel.



2. Aluminum (Al)

During steelmaking, aluminum is a powerful deoxidizer (forming Al2O3 inclusions), which can remove dissolved oxygen from steel, purify the molten steel, and reduce defects such as porosity and inclusions. After solidification, fine Al2O3 particles can act as "heterogeneous nucleation sites", refining the steel's grain structure and enhancing its strength and toughness. In stainless steel, aluminum promotes the formation of an Al2O3 protective film on the surface, enhancing resistance to strong oxidizing acids (such as nitric acid) and expanding the application scenarios of stainless steel (such as nitric acid industrial equipment).



IV. Special Function Elements



Boron (B)

Boron atoms tend to cluster at grain boundaries, strongly inhibiting the ferrite precipitation at austenite grain boundaries, significantly reducing the critical cooling rate and exponentially enhancing the steel's hardenability. The strengthening effect of a very small amount of boron (w(B) = 0.001%) is equivalent to that of a large amount of elements such as manganese, nickel, and chromium, which can significantly reduce the alloy usage and costs. The borides formed by the combination of boron with nitrogen and oxygen (such as Fe2B) have extremely high hardness and can be used in steels requiring surface wear resistance (such as boron steel gears) to achieve a performance match of "surface hardening + core toughness" by controlling the distribution of borides.



2. Rare earths (RE, represented by Ce and La)

In steelmaking, rare earths can effectively desulfurize (forming high-melting-point rare earth sulfides), degas (adsorbing gases such as H and N), purify molten steel, and reduce harmful inclusions. During solidification, rare earth elements adsorb at grain boundaries, inhibit columnar crystal growth, refine equiaxed crystal structure, and improve the hot cracking tendency and mechanical property uniformity of cast steel. In high-temperature alloys, rare earths can strengthen grain boundaries and enhance high-temperature creep resistance, making them an "invisible strengthening agent" for high-end alloys such as turbine disk alloys for aircraft engines.



V. Auxiliary Performance Optimization Elements



1. Copper (Cu)

Low content (w(Cu) < 1.5%): It strengthens ferrite in a solid solution form, enhancing strength. In the atmosphere, copper can promote the formation of a "copper-rich layer" on the steel surface, accelerating the densification of the oxide film and improving weather resistance (such as weathering steel for construction), achieving "anti-corrosion through rust".

High content (w(Cu) ≥ 3.0%): Copper precipitates as fine metal particles, generating "precipitation hardening", and simultaneously endowing steel with unique antibacterial properties (copper ions disrupt bacterial cell membranes), showing great application potential in medical steel and steel for public facilities.



2. Lead and bismuth (Pb, Bi)

Because they are insoluble in the steel matrix, they are distributed as discrete fine particles at the grain boundaries/matrix. During cutting, they can act as "lubricants and chip breakers" - the particles interrupt the transmission of cutting force, reduce tool wear, make chips easier to break, significantly improve the machinability of steel (such as free-cutting steel), balance the strength of steel and processing efficiency, and are suitable for batch processing scenarios such as automotive fasteners and electronic components.



3. Titanium (Ti) and Niobium (Nb)

In the performance optimization of steel materials, titanium and niobium are indispensable key elements. They refine the grain structure of steel. By acting as nucleation cores during the solidification of molten steel, they increase the number of grains and reduce their size, thereby significantly enhancing the strength, toughness and fatigue resistance of steel. In the field of stainless steel, titanium and niobium can combine with carbon to form stable carbides, preventing chromium from combining with carbon to form chromium carbides, and thus avoiding the occurrence of chromium-depleted grain boundaries. This effectively improves the intergranular corrosion resistance of stainless steel, ensuring its long-term stable service in strongly corrosive environments such as chemical engineering and food processing.



4. Zirconium (Zr)

Zirconium, as a strong deoxidizer and denitrogenizer, can rapidly combine with oxygen and nitrogen in molten steel to form stable compounds that float to the surface of the steel, effectively reducing the content of oxygen and nitrogen impurities in the steel and purifying the molten steel. At the same time, zirconium can refine austenite grains, making the steel structure more uniform and dense, and improving the comprehensive performance of the steel. It combines with sulfur to form zirconium sulfide, a compound with a high melting point and good thermal stability, which can effectively prevent the hot brittleness problem caused by sulfur, ensuring that the steel does not crack or break during hot working, and improving the hot working performance and product quality of the steel.



5. Tungsten (W)

Tungsten forms fine carbides and nitrides in steel, which inhibit the growth of grains at high temperatures, making the steel's grains finer and more uniform, thereby enhancing the steel's strength and toughness. In terms of hardenability, tungsten can reduce the critical cooling rate of steel, making it easier for steel to obtain martensitic structure during quenching, and improving the hardness and wear resistance of steel. At high temperatures, it combines with carbon and nitrogen to form highly thermally stable carbides (such as W₂C) and nitrides (such as W₂N), which can effectively hinder dislocation movement, significantly improving the thermal strength of steel, and enabling steel to maintain good strength and stability under harsh conditions such as high temperature and high pressure. It is an important alloying element for manufacturing key components such as aero-engine blades and high-temperature furnace tubes.



6. Cobalt (Co)

In high-temperature environments, cobalt can stabilize the microstructure of steel, prevent grain growth and softening, and maintain high hardness and wear resistance of steel at high temperatures. It is suitable for manufacturing high-temperature cutting tools, hot extrusion dies, etc. When cobalt and molybdenum work together, they can fully leverage their respective advantages and produce a strong synergistic effect, endowing steel with extremely high strength and excellent comprehensive mechanical properties. This combination is widely used in high-end fields such as aerospace and national defense, for manufacturing components with extremely demanding performance requirements, such as turbine discs for aircraft engines and rocket engine casings.



7. Beryllium (Be)

Beryllium is added in small amounts to steel. It has a strong affinity for oxygen and sulfur and can quickly combine with them during the steelmaking process, exerting a powerful deoxidizing and desulfurizing effect, effectively reducing the content of harmful impurities in steel and purifying the molten steel. It enhances the hardenability of steel and alters its phase transformation behavior, making it easier to obtain the desired microstructure and properties during quenching. Moreover, beryllium has a very strong solid solution strengthening effect. When dissolved in the steel matrix, it causes severe lattice distortion, greatly hindering dislocation movement and thus generating a powerful strengthening effect. When combined with iron and carbon, beryllium can also produce a very strong precipitation strengthening effect by forming special compounds, further enhancing the strength and hardness of steel, and giving it unique application value in high-end manufacturing industries.
